Magnum DS low-voltage switchgear
Eaton’s Magnum DS low-voltage switchgear offers reliable protection and centralized control of low-voltage power circuits up to 600 volts for a wide range of industries including healthcare, data centers and petrochemical. Low-voltage switchgear is a metal-enclosed assembly with three-position, draw-out power circuit breakers engineered to monitor and protect low-voltage electrical systems.

VOLTAGE CLASS
Up to 600 V
CONTINUOUS CURRENT
Up to 10000 A
INTERRUPT RATING
Up to 200 kAIC
Core features
- Draw-out LV power circuit breakers with 100%-rated, fully selective protection and integral microprocessor-based breaker tripping systems
- Engineered-to-order configurations available to accommodate a wide range of applications
- Complies with UL® 1558 and UL® 891 safety standards
- Rear-access model equipped with standard rear-bolted covers that consist of two sections to enable easy handling during installation and removal; optional rear doors
- Silver plated copper bus standard, tin plated optional
- NEMA® 1 indoor and NEMA® 3R outdoor enclosure designs available
Image gallery
Scroll to view various images of metal-clad equipment
Previous
Next
More breakers per structure, in half the size!
Series NRX breakers provide similar protection, features and performance as Magnum DS breakers but in a more compact form factor. When using NRX breakers, a 24-inch structure can house as many as eight breakers reducing the overall assembly size by as much as half.
Modernize and extend the life of Magnum DS low-voltage switchgear
Genuine Magnum DS switchgear accessories and replacement parts improve the reliability, safety and longevity of the switchgear.
Compact designs, even for 4000A applications.
The MDN4000 is a narrow-design low-voltage circuit breaker in a 30-inch structure featuring an interrupt rating of 100 kAIC at 508 VAC and 65 kAIC at 635 VAC. The MDN4000 is available for rear-access Magnum DS, as well as all of Eaton’s front access and front-access arc-resistant low-voltage switchgear products.
